| MODEL NO. | AP20 | AP30 | AP20-NDI | AP30-NDI |
| INTERFACES | Video Out | SDI, HDMI |
| LAN Port | IP Streaming: RTSP/RTMP/SRT |
| POE | POE | POE&NDI丨 HX | POE&NDI丨 HX |
| Audio Input | 3.5mm audio (Line-level) |
| Control Interface | RS-232 In and Out, RS485 In |
| Control Protocol | Onvif, VISCA over IP/ VISCA/ Pelco-D/P |
| Video Format | HDMI/ SDI Video up to 1080P60 |
| CAMERA PARAMETERS | Optical Zoom | 20× | 30× | 20× | 30× |
| Focal Length | F=5.5~110mm | F=4.3~129mm | F=5.5~110mm | F=4.3~129mm |
| View Angle | 3.3°(tele) | 2.34°(tele) | 3.3°(tele) | 2.34°(tele) |
| 54.7°(wide) | 65.1°(wide) | 54.7°(wide) | 65.1°(wide) |
| Aperture Value | F1.6 ~ F3.5 | F1.6 ~ F4.7 | F1.6 ~ F3.5 | F1.6 ~ F4.7 |
| Sensor | 1/2.8 inch, High quality HD CMOS sensor |
| Effective Pixels | 16: 9, 2.07 Megapixel |
| Digital Zoom | 10× |
| Minimum Illumination | 0.5Lux (F1.8, AGC ON) |
| DNR | 2D & 3D DNR |
| SNR | >55dB |
| White Balance | Auto/ Manual/ One Push/ 3000K/ 3500K/ 4000K/ 4500K/ 5000K/ 5500K/ 6000K/ 6500K/ 7000K |
| WDR | OFF/ Dynamic level adjustment |
| Video Adjustment | Brightness, Color, Saturation, Contrast, Sharpness, B/W mode, Gamma curve |
| Other Camera Parameters | Auto Focus, Auto Aperture, Auto Electronic Shutter, BLC |
| PTZ PARAMETERS | Rotation Angle | Pan: ±170°, Tilt: -30°~+90° |
| Rotation Speed | Pan: 60°/sec (Range: 0.1 -180°/sec), Tilt: 30°/sec (Range: 0.1-80°/sec) |
| Preset Number | 255 presets (10 presets by remote controller) |
| OTHERS | Input Voltage | DC12V±10% |
| Input Current | 1A (Max) |
| Consumption | 12W (Max) |
| Temperature | Working Temperature: -10~+50°C, Store Temperature: -10~+60°C |
| Working Humidity | Working Humidity: 20~80% RH (no condensation), Store Humidity: 20~95% RH (no condensation) |
| Dimension | 170×170×180.31mm |
| Weight | Net weight: 1.25kg; Gross weight: 2.1kg |
| Accessories | Power Supply, RS232 Control Cable, Remoter, Manual |
| Installation Methods | 1/4 inch tripod hole; Bracket installation for Optional |
